Patient Benefits
Sleep the way they want
- Top-of-head tube design gives patients the freedom to sleep in any position.
Intuitive design
- UltraCompact full face cushion design is curved for stability and improved seal performance.
- Flexible conduit frame allows pressurized air to flow through the elbow and into the frame and cushion.
- Magnetic clips make it easy to securely connect the bottom of the headgear to the frame.*
- Quick-release elbow allows for easy disconnection. It stays attached to the tubing to ensure mask parts don’t get lost or stuck.
Get closer to their partner
- With no front-end tube, the mask stays out of sight and out of the way.
* Magnets may interfere with certain implants or medical devices. Please refer to the User Guides for complete information, including magnet contraindications and warnings.
Fitting Guide
- With one hand holding the bottom of the cushion and the other holding the conduit frame, position the mask in front of the face.
- Place the cushion under the nose and against the face. With the ResMed logo and headgear facing up, pull the headgear over the head.
- Bring the lower headgear straps under the ears and attach the magnetic clips to the frame connectors.
- Undo the fastening tabs on the upper headgear straps and pull evenly.
- Repeat with the lower headgear straps.
- Squeeze the side buttons on the elbow and detach from the frame. Connect the air tubing from the device to the elbow, then reattach it to the frame.
| Complete mask system | |
|---|---|
| (Includes mask frame, full face cushion and headgear) | |
| AirFit F30i system – S/SML | 63330 |
| AirFit F30i system – S/STD | 63331 |
| AirFit F30i system – M/STD | 63332 |
| AirFit F30i system – W/STD | 63333 |
| AirFit F30i system – M/LGE | 63334 |
| Full face cushion | |
| AirFit F30i cushion SML | 63350 |
| AirFit F30i cushion MED | 63351 |
| AirFit F30i cushion SML – WIDE | 63352 |
| AirFit F30i cushion WIDE | 63353 |
| Headgear | |
| AirFit F30i headgear – STD | 63372 |
| Frame system | |
| (Includes mask frame and full face cushion) | |
| AirFit F30i frame system – S/SML | 63355 |
| AirFit F30i frame system – M/SML | 63356 |
| AirFit F30i frame system – SW/SML | 63357 |
| AirFit F30i frame system – W/SML | 63358 |
| AirFit F30i frame system – S/STD | 63359 |
| AirFit F30i frame system – M/STD | 63360 |
| AirFit F30i frame system – SW/STD | 63361 |
| AirFit F30i frame system – W/STD | 63362 |
| AirFit F30i frame system – S/LGE | 63363 |
| AirFit F30i frame system – M/LGE | 63364 |
| AirFit F30i frame system – SW/LGE | 63365 |
| AirFit F30i frame system – W/LGE | 63366 |
| Conduit mask frame | |
| (Does not include full face cushion) | |
| AirFit F30i conduit – SML | 63368 |
| AirFit F30i conduit – STD | 63369 |
| AirFit F30i conduit – LGE | 63370 |
Disassembly
Undo the fastening tabs on the upper headgear straps and pull from the frame. Keep the magnetic clips attached to the lower headgear straps.
Undo the fastening tabs on the upper headgear straps and pull from the frame. Keep the magnetic clips attached to the lower headgear straps.
Squeeze the side buttons on the elbow and detach from the frame.
Reassembly
Align and insert the frame connector tab (a) into the cushion slot (b) and press down until it clicks. Repeat on the other side
Attach the elbow to the top of the frame until it clicks.
.jpg?width=144&height=144&name=assemble_airfit-f30i-3%20(1).jpg)
With the ResMed logo facing outwards and up, insert the upper headgear straps into the frame from the inside and fold the fastening tabs over to secure.
